P   ­€‚
Earthed plug and
control box
The 230 V version is delivered
ready for operation with
control box and earthed plug.
CEE connector +
protection switch
The 400 V version is delivered
ready-to-connect with 5-pole CEE plug
and motor protection switch.
MIDI II 4.0 kW/400 V MIDI II 1.1 kW/230 V
Recommendation
Two different motor power ratings with
regulation-conformant earthed plugs
(230V) and motor circuit breaker or CEE
plug (400 V) offer solutions for different
bodies of water and conditions.
Optimized water pressure creates
impressive heights for the four available
nozzle patterns with 3" standard thread for
fast changing.
The easy-to-install LunAqua illumination
set provides impressive lighting of the water
pattern with a height of up to 16.5m.
Top product characteristics
• Easy to install
• Low-maintenance
• Appealing design
*page310
T„ ­ €   ‚
MIDI II 1.1 kW / 230 V MAXI II 4.0 kW / 400 V
Dimensions incl. Nozzle (Ø x H) mm 1030 x 1000 1030 x 1460
Rated voltage 230 V / 50 Hz 400 V / 50 Hz
Power kW 1.1 4
Power cable length m 50.00 50.00
Max. head height m 22.80 46.60
Net weight kg 80.00 105.00
Guarantee *P.310 Years 2 2
Max. flow rate l/min 366 650
Max. flow rate l/h 22000 39000
Connection pressure-side mm 75 75
Connection pressure-side 3” 3”
Water depth, min. m 1.00 1.15
Item no. (GB-Version) – –
Item no. 50371 50371
