OASE | Catalogue 2017 - page 90

Sets Pressure filter UVC power Filter pump &
watercourse pump
+ Aerators
(accessories)
Suitable for
pond volume in m3 Item no. Item no.(GB-Version)
Table explanations:
In the marked rows you will find the complete filter sets. The other groupings are additional possible combinations for different
requirements and pond sizes.
BioPress
Set 4000 BioPress 4000 7W (UVC integrated) FP 1500 – 4 2 1 50499 50504
Set 6000 BioPress 6000 9W (UVC integrated) FP 2500 – 6 3 1.5 50453 50454
Set 10000 BioPress 10000 14W (UVC integrated) FP 3500 – 10 5 2.5 50455 50457
The following were considered for the BioPress Sets: 5 m 1" hose and a delivery head of max. 0.5 m
FiltoClear
FiltoClear 3000 9W (UVC integrated) AquaMax Eco Classic 2500 – 1.5 0.75 –
+ OxyTex Set 500 1.7 1 –
Set 3000 FiltoClear 3000 9W (UVC integrated) AquaMax Eco Premium 4000 – 3 1.5 – 50864 50869
+ OxyTex Set 500 3.5 1.8 –
FiltoClear 6000 11W (UVC integrated) AquaMax Eco Premium 4000 – 4 2 –
+ OxyTex Set 500 4.5 2.5 –
Set 6000 FiltoClear 6000 11W (UVC integrated) AquaMax Eco Premium6000 – 6 3 – 50867 50871
+ OxyTex Set 500 7 3.5 –
FiltoClear 12000 18W (UVC integrated) AquaMax Eco Premium 4000 – 6 3 1.5
+ OxyTex Set 1000 7 3.5 1.5
FiltoClear 12000 18W (UVC integrated) AquaMax Eco Premium6000 – 8 4 2
+ OxyTex Set 1000 10 5 2.5
Set 12000 FiltoClear 12000 18W (UVC integrated) AquaMax Eco Premium8000 – 12 6 3 51250 51252
+ OxyTex Set 1000 14 7 3.5
FiltoClear 16000 24W (UVC integrated) AquaMax Eco Premium6000 – 9 5 2.5
+ OxyTex Set 1000 10 5 2.5
FiltoClear 16000 24W (UVC integrated) AquaMax Eco Premium8000 – 12 6 3
+ OxyTex Set 1000 15 8 4
Set 16000 FiltoClear 16000 24W (UVC integrated) AquaMax Eco Premium 10000 – 16 8 4 51253 51254
+ OxyTex Set 1000 19 9.5 5
FiltoClear 20000 36W (UVC integrated) AquaMax Eco Premium 10000 – 18 9 4.5
+ OxyTex Set 2000 22 11 5.5
Set 20000 FiltoClear 20000 36W (UVC integrated) AquaMax Eco Premium 12000 – 20 10 5 50877 50881
+ OxyTex Set 2000 25 12.5 6
FiltoClear 30000 55W (UVC integrated) AquaMax Eco Premium 12000 – 26 13 6.5
+ OxyTex Set 2000 32 16 8
Set 30000 FiltoClear 30000 55W (UVC integrated) AquaMax Eco Premium 16000 – 30 15 7.5 50885 50888
+ OxyTex Set 2000 36 18 9
For the pond size specifications cited above (FiltoClear/sets) 1 m delivery head and 5 m 1½" hose were taken into consideration. Larger pumps should be used for longer hose lengths and/or
greater delivery heads. Clear Water Guarantee * P.310 in accordance with a light penetration depth of 1 m, using a Secchi disk. Please note that in case of extreme temperature fluctuations, friction
losses for hose lines longer than 5 m, or direct sunlight due to the position of the pond (south facing), more intensive planning is required.
All references regarding our Filter/UVC combinations for special pond sizes are based on Mid-European climatic conditions. For other regions they could differ due to the water temperature
and sun intensity.
Sets Underwater filter UVC power Filter pump &
watercourse pump
+ Aerators
(accessories)
Suitable for
pond volume in m3 Item no. Item no.
(GB-Version)
Table explanations:
In the marked rows you will find the complete filter sets. The other groupings are additional possible combinations for different
requirements and pond sizes.
Filtral UVC 3000* (Filter integrated) 7W (UVC integrated) (pump integrated) – 3.0 1.5 – – 51232
Filtral UVC 6000* (Filter integrated) 9W (UVC integrated) (pump integrated) – 6.0 3.0 – – 51233
Filtral UVC 9000* (Filter integrated) 11W (UVC integrated) (pump integrated) – 9.0 4.5 – – 51235
Filtral UVC 2500 (Filter integrated) 7W (UVC integrated) (pump integrated) – 2.5 1.3 – 50446 –
Filtral UVC 5000 (Filter integrated) 11W (UVC integrated) (pump integrated) – 5.0 2.5 – 57379 –
*Exclusively available in GB!
Clear Water Guarantee*P.310 as specified by Secchi, to a visual depth of 1 m.
Filter comparison
2m
Underwater filter Filtral UVC Pressure filter FiltoClear Set
Important note
When planning a new pond
with koi stock, please ensure
a minimum pond size of 5 m3 !
Ponds with plants,
without fish stock
Ponds with plants and fish stock
up to 1 kg/1000 l (no koi)
Ponds with plants and fish stock
upto1–2kg/1000 l (koi ponds)
