AquaMax Eco Titanium 30000–50000
Q
(l/min)
100 200 300 400 500 600 700 800
H
(mWS)
2
4
3
1
50000 MAX
50000 MIN
30000 MAX
30000 MIN
81
NEW
*page310
T
AquaMax Eco
Titanium 30000
AquaMax Eco
Titanium 50000
Dimensions (L x W x H)
mm
275 x 175 x 215
350 x 220 x 245
Rated voltage
220 - 240 V / 50/60 Hz
Power consumption
W
25 - 180
70 - 320
Power cable length
m
10.00
Net weight
kg
10.00
16.50
Guarantee (+ request guarantee)
*P.310
Years
3 + 2
Max. flow rate
l/min
500
800
Max. flow rate
l/h
30000
48000
Max. head height
m
3.00
4.00
Connection pressure-side
mm
63
75
Connection pressure-side
2 ½”
3”
Connection sunctions-side
mm
63
75
Connection sunctions-side
2 ½”
3”
Coarse debris displacement max.
mm
6
Connection EGC
Yes
Electronically adjustable
Yes
Setup type
Can be setup underwater & dry
Item no. (GB-Version)
−
Item no.
47028
39918
Accessories
Safety grid AquaMax Eco Titanium
50000
Optional safety attachment for
wet setup in a pump chamber,
prevents unintentional debris
reaching the suction inlet.
Item no. 43329 page 77
Connection Cable EGC 2.5 m
Item no. 47038 page 77
Connection Cable EGC 5.0 m
Item no. 47039 page 77
Connection Cable EGC 10.0 m
Item no. 47040 page 77
Cable connector EGC
Item no. 47788 page 77
InScenio FM-Master WLAN
This innovative garden power
outlet can be controlled via smart
phone or tablet. In addition to 4
power outlets with an integrated
timer, it also has an EGC connec-
tion.
Item no. 40243 page 242
InScenio FM-Master WLAN EGC
Item no. 47035 page 242
Robust pump housing
Cast stainless steel enables achievement
of sustainable above-average precision
and energyefficiency. The entire pump
housing can be adjusted 90° upward.
Special channel-type impeller
The impeller is impressive through its
extremely long service life. Even under
continuous load, signs of wear cannot be
detected.
Connection for EGC
Innovative and convenient, the pump can
be regulated and operated through
control devices such as the AquaMax Eco
Control (included in the scope of
delivery).
P
Recommendation
AquaMax Eco Titanium 30000 and 50000
are outstandingly suited in this regard, e.g.
through a drum filter, then cleaned water
is energy-efficiently conveyed back into the
pond, even over long distances. The clever
Eco Control with an illuminated two-line
display is equipped with a 10 m EGC cable.
Enabling the pump to be conveniently
dimmed, power consumption is displayed;
as well as speed and total runtime. Extend
the service life of your pump and ensure
lasting high performance with the special
AquaActiv PumpClean cleaner.
Top product characteristics
• Network-capable, high-performance
powerhouse for large gravitation filter
installations
• With the innovative Eco Control for regu-
lation and control, included in the scope
of delivery.
• With the SFC function switched on, an
additional 30% savings in energy costs,
depending on the water temperature is
possible
OASE-Pump performance curves – comparison see page 303–306
