71
AquaMax Eco Premium 6000 - 12000/12V
Q
(l/min)
H
(mWS)
3
1
100
50
150
200
1.5
2
2.5
3.5
12000 /12V
6000 /12V
Accessories
P
12 V power unit
For safety, low voltage transformer, suita-
ble for swim ponds. Power unit must be
setup at least 2 m from the pond.
Regulator + 2nd inlet
Second inlet allows for connection of a
satellite filter or surface skimmer. The
sliding function allows adjustment of
skimmer or satellite filter capacity in
4 steps from 0 to 100%.
Top product characteristics
•
Outstanding energy efficiency and
displacement capacity
• Perfect in swim ponds and bathing ponds
thanks to safe 12-volt technology
• Simultaneous supply of debris through
connection of filter accessories on the
patented, second inlet
Matching filters and filter systems starting on page 94
Satellite filter AquaMax Eco
Enables intake of polluted water at an
additional point on the pond floor.
Item no. 57177
(page 77)
Extras
Recommendation
Extend the service life of your pump and
ensure lasting high performance with
the special AquaActiv PumpClean cleaner
(page 210).
*page310
T
AquaMax Eco
Premium
6000 / 12 V
AquaMax Eco
Premium
12000 / 12 V
Dimensions (L x W x H)
mm
340 x 280 x 165
Rated voltage (primary, secondary)
230 V / 50 Hz, 12 V / DC
Power consumption
W
55
100
Cable length 12 V device
m
2.50 (Power unit) + 8.00
Net weight
kg
8.70
10.60
Guarantee (+ request guarantee)
*P.310
Years
3 + 2
Max. flow rate
l/min
100
190
Max. flow rate
l/h
6000
11400
Max. head height
m
3.20
Connection pressure-side
mm
50
Connection pressure-side
2”
Connection sunctions-side
mm
50
Connection sunctions-side
2”
Connection for hoses
mm
25 / 32 / 38
25 / 32 / 38 / 50
Connection for hoses
1”, 1 ¼”, 1 ½”
1”, 1 ¼”, 1 ½”, 2”
Filter intake surface
cm²
1000
Coarse debris displacement max.
mm
10
11
Electronically adjustable
No
Setup type
Can be setup underwater & dry
Item no. (GB-Version)
−
Item no.
50730
50382
OASE-Pump performance curves – comparison see page 303–306
F
&W
F
&W
AquaSkim 20 Item no. 51236 (page 174)
AquaSkim 40 Item no. 56907 (page 174)
Skimmers for powerful suctioning of pond
surfaces. Remove particles before they
settle and impair the water quality.
