AquaMax Eco Expert 21000 - 26000
Q
(l/min)
H
(mWS)
450
6
7
8
9
2
1
200
150
100
3
4
5
26000
21000
250 300
400
350
OASE-Pump performance curves – comparison see page 303–306
75
*page310
T
AquaMax Eco
Expert 21000
AquaMax Eco
Expert 26000
Dimensions (L x W x H)
mm
490 x 215 x 210
Rated voltage
220 - 240 V / 50/60 Hz
Power consumption
W
40 - 350
60 - 440
Power cable length
m
10.00
Net weight
kg
12.00
Guarantee (+ request guarantee)
*P.310
Years
3 + 2
Max. flow rate
l/min
350
433
Max. flow rate
l/h
21000
26000
Max. head height
m
8.00
8.50
Connection pressure-side
mm
50
Connection pressure-side
2”
Connection sunctions-side
mm
50
Connection sunctions-side
2”
Connection for hoses
mm
38 / 50
Connection for hoses
1 ½”, 2”
Filter intake surface
cm²
1060
Coarse debris displacement max.
mm
11
Connection EGC
Yes
Electronically adjustable
Yes
Setup type
Can be setup underwater & dry
Item no. (GB-Version)
−
Item no.
39916
39917
Accessories
Eco Control
With the clever EGC control device,
the capacity of the connected
pumps can be simultaneously
accessed and regulated directly
on the controller. Including illumi-
nated display - without separate
power supply!
Item no. 47673 page 76
InScenio FM-Master WLAN
This innovative garden power
outlet can be controlled via smart
phone or tablet. In addition to 4
power outlets with an integrated
timer, it also has an EGC connec-
tion.
Item no. 40243 page 242
InScenio FM-Master WLAN EGC
Item no. 47035 page 242
Compact base
Integrated fixing holes in the base facili-
tate fixed installation on the pond floor,
as needed.
Convenient operation
The ergonomic handle, aligned with the
pump's centre of gravity facilitates trans-
port and installation. The switch for SFC
function is practically positioned directly
on the handle.
P
Recommendation
The energy-efficient and high-performance
AquaMax Eco Expert is outstandingly suit-
ed for feeding large filter systems, as well
as demanding watercourses and waterfalls.
Innovative controller and new FM-Master
WLAN with EGC interface for individual ca-
pacity regulation and query, as accessories.
Extend the service life of your pump and
ensure lasting high performance with the
special AquaActiv PumpClean cleaner.
Top product characteristics
• Suitable for networks, powerhouse with
low energy consumption!
• Patented frost protection to -20°C
• With switchable SFC function, enabling
an additional 30% savings in energy costs,
depending on the water temperature
Robust filter basket
Thanks to this robust stainless steel filter
basket, coarse debris particles up to 11
mm are displaced with no problems.
Connection for EGC
Innovative, convenient and handy, via an
EGC connection the Eco Expert pumps
can be regulated and operated by control
devices, such as the AquaMax Eco Con-
trol.
