77
T
Satellite
filter
AquaMax Eco
Safety grid
AquaMax
Eco Titanium
50000
Add. pack
AquaMax Eco
1” - 1 1/2”
Add. pack
AquaMax Eco
1 1/2”
Add. pack
AquaMax
Eco 2”
Hosetail set
AquaMax
Eco 2” / DA 63
Pipe connec-
tor AquaMax
Eco DA 75/
DA 110
Dimensions (L x W x H)
mm 370 x 260 x 100 95 x 95 x 70 65 x 65 x 150 65 x 65 x 90 65 x 65 x 90 65 x 65 x 125
115 x 115 x 95
Net weight
kg
0.45
0.80
0.25
0.05
0.06
0.08
0.17
Connection pressure-side
mm
-
-
50
50
50
50
50
Connection pressure-side
-
-
2”
2”
2”
2”
2”
Connection for hoses
mm 25 / 32 / 38
-
25 / 32 / 38
38
50
50 / 63
-
Connection for hoses
1”, 1 ¼”, 1 ½”
-
1”, 1 ¼”, 1 ½”
1 ½”
2”
2”, DA 63 DA 75, DA 110
Coarse debris displacement max.
mm
11
-
-
-
-
-
-
Item no. (GB-Version)
−
Item no.
57177
43329
17272
17064
17069
35577
35578
T
NEW
Connection Cable
EGC 2.5 m
Connection Cable
EGC 5.0 m
Connection Cable
EGC 10.0 m
Cable connector
EGC
Power cable length
m
2.50
5.00
10.00
-
Cable cross section
mm²
0.22
-
Protection class
IP 68
Net weight
kg
0.39
0.69
1.29
0.02
Guarantee
*P.310
Years
2
Product characteristics
• Special cable suitable for underwater use for bi-directional communication, e.g. between pumps, filters and control devices
• 4-wire, shielded cable with a plug-and-socket connection
Item no. (GB-Version)
Item no.
47038
47039
47040
47788
T
Spare parts case
O-Ring PN 48 x 4 SH75
EA
40
hose connector 2”
EA
6
Coupling nut 1 1/2 “
EA
6
Retaining nut 2”
EA
4
Passage banner FiltoClear 30000
EA
15
Flat gasket NBR 40 f. outlet 70
EA
20
O-Ring Viton 32 x 4 SH70
EA
40
Flat gasket hose tail 1 1/2”
EA
40
Flat gasket NBR 60 x 47 x 3 SH40
EA
40
Flat gasket grommet 2” D56.3 x 3
EA
40
O-Ring NBR 330 x 8 SH35
EA
5
Passage banner FiltoClear
EA
15
Stepped hose tail 1 1/2” black
EA
10
Stepped hose tail - ball
EA
5
Union nut 2”, ball
EA
4
O-Ring NBR 60 x 2.5 SH70 A
EA
20
Flat gasket NBR/SBR 57 x 48 x 3 SH80
EA
40
Stepped hose tail 2”
EA
5
Stepped hose tail 1 1/2” clear
EA
5
Item no.
57239
