Extras
33
Product details
External control system
Compact and easy to conceal: The control
unit can be easily connected and includes
a transformer as well as a ground stake.
Illuminated nozzles
The individually controllable nozzles,
each with 6 LEDs, are easy to align.
Height adjustable
The nozzles of the fountain are height
adjustable, so that the water level can
vary by 20 cm.
Remote control
The remote control unit included in the
scope of delivery has a range of up to
80 m without obstruction.
Top 3 product characteristics
• Remote controlled water feature
with varying fountains and white
LED illumination
• Water patterns can be selected from
the set programs
• Can be used in swim ponds
*
P.251
Technical data
Water Quintet
Dimensions (L x W x H)
mm
430 x 300 x 240
Net weight
kg
11.30
Guarantee (+ request guarantee)*
P.251
Years
2 + 1
Light colour
Neutral white
Cable length 12 V device
m
2.50 (power unit) + 8.00
Fountain height, max.
m
1.40
Jet diameter
mm
5
12V conrol box
Dimensions (L x W x H)
mm
215 x 180 x 305
Power consumption
W
50
Rated voltage, primary (control system)
V
12
Hand-held transmitter/range max.
m
80.00
Power unit
Dimensions (L x W x H)
mm
160 x 100 x 100
Rated voltage (primary, secondary)
230 V/50 Hz , 12 V/DC
Item no.
50187
Accessories
Pond liner
Almost any idea can be a reality
with OASE pond liners.
Additional information
(page 221)
Recommendation
Splash water can be minimised by
selecting a pool with at least a 3 m
diameter. The OASE water reservoir
WR 100 can be extended with pond liner,
for example.
Water reservoir cover
Trio /Quintet
Tailored opening for the
»Water Trio« and »Water
Quintet« fountains.
Additional service opening
with cover.
Item no. 50327 (page 241)
Water reservoir WR 100
The weather-resistant solution
for flexible installation.
Item no. 37112
(page 241)
Fountains & Fountain Pumps
Water Entertainment
