Extras
25
Hose connectors
The innovative hose connector makes the
installation easy. The power cable can
be routed out through the opening and
does not need to be threaded through the
entire length of the hose.
Stainless steel cap
The high quality stainless steel cap enables
fast adjustment of the water flow rate and
protects the LED from damage.
Amount of water required
The right pump is crucial for an appro
priate fountain height; it is best to select
the pump based on the water flow rate.
Do not forget that hose length and
diameter also play a role.
Product details
Top 3 product characteristics
•
High quality stainless steel cap
•
Easy installation via hose connectors,
ideal for bubbling stones
•
Adjustable water feature height
Recommendation
Be creative – combine multiple LunaLeds
using the OASE multiple distributor (page
230) and design your custom fountain.
Recommended
supplemental products
Water feature pumps
Aquarius Universal page 48–51
Additional pond construction material,
such as
hoses, hose connectors, etc.
from page 227
LunaLed 6 s LunaLed 9 s
Height l/min Height l/min
2 cm 3
2 cm 7
3.5 cm 5 3.5 cm 9
6 cm 6
6 cm 11
12 cm 8 12 cm 14
*
P.251
Technical data
LunaLed
6 s
LunaLed
9 s
Dimensions (Ø x H)
mm
30 x 70
50 x 70
Rated voltage (primary, secondary)
230 V/50 Hz , 12 V/DC
Power consumption light fixture
< 1 W
Power consumption set
W
2
Protection class
IP 44, IP 68 (power unit)
Power cable length
m
10.00
Net weight
kg
0.60
0.80
Guarantee*
P.251
Years
2
Connection inlet
mm
19
25
Connection inlet
¾"
1"
Illuminant type
LED
Number of individual LEDs
EA
6
9
Light flux
lm
8
10
Light colour
Cold-white
Half peak angle
Degrees
72
Item no. (GB-Version)
Not available in GB !
Item no.
50114
50115
Dimension drawing:
LunaLed 6 s
Dimension drawing:
LunaLed 9 s
These products are on page 193
Fountains & Fountain Pumps
Water Entertainment
