Extras
AquaMax Eco Premium 6000 - 12000/12V
Q
(l/min)
H
(mWS)
3
1
100
50
150
200
1.5
2
2.5
3.5
12000 /12V
6000 /12V
73
Technical data
AquaMax Eco
Premium
6000 / 12 V
AquaMax Eco
Premium
12000 / 12 V
Dimensions (L x W x H)
mm
340 x 280 x 165
Rated voltage (primary, secondary)
230 V/50 Hz , 12 V/DC
Power consumption
W
55
100
Cable length 12 V device
m
2.50 (power unit) + 8.00
Net weight
kg
8.70
10.60
Guarantee (+ request guarantee)*
P.251
Years
3 + 2
Max. flow rate
l/min
100
190
Max. flow rate
l/h
6000
11400
Max. head height
m
3.20
Connection pressure-side
mm
50
Connection pressure-side
2"
Connection suctions-side
mm
50
Connection suctions-side
2"
Connection for hoses
mm
25/32/38
25/32/38/50
Connection for hoses
1", 1¼", 1½"
1", 1¼", 1½", 2"
Filter intake surface
cm²
1000
Coarse debris displacement max.
mm
10
11
Electronic adjustment
No
Setup type
Can be setup underwater & dry
Item no.
50730
50382
Accessories
Product details
12V Power unit
For safety, low voltage transformer,
suitable for swim ponds. Power unit must
be setup at least 2 m from the pond.
Regulator + 2nd inlet
Flow through from 0 to 100% can be
mechanically adjusted. Ideal for adjusting
skimmer or satellite filter capacity (acces-
sories) in 4 steps. 2. Inlet allows connection
of a satellite filter or a surface skimmer
(accessories).
Top 3 product characteristics
•
Outstanding energy efficiency and
displacement capacity
• Perfect in swim ponds and bathing ponds
thanks to safe 12-volt technology
• Simultaneous supply of debris through
connection of filter accessories on the
patented, second inlet
OASE-Pump performance curves – comparison see page 246–247
Matching filters and filter systems starting on page 84
AquaSkim 20
Item no. 51236 (page 162)
AquaSkim 40
Item no. 56907
(page 162)
Effectively frees the pond surface of leaves,
food remnants, and other pollutants and
carries pollutants directly to the filter system.
Satellite filter AquaMax Eco
Enables intake of polluted
water at an additional point
on the pond floor.
Item no. 57177
*
P.251
Filter- &Watercourse pumps
AquaMax
