Extras
AquaMax Expert 20000 – 40000
Q
(l/min)
100
200
300
400
500
600 700
H
(mWS)
8
10
12
6
4
2
40000
30000
20000
*
P.251
Technical data
AquaMax
Expert
20000
AquaMax
Expert
30000
AquaMax
Expert
40000
Dimensions (L x W x H)
mm
420 x 240 x 260
461 x 258 x 293
Rated voltage
220–240 V/50 Hz
Power consumption
W
450
650
1100
Power cable length
m
10.00
Net weight
kg
13.90
19.20
Guarantee (+ request guarantee)*
P.251
Years
3 + 2
Max. flow rate
l/min
333
500
683
Max. flow rate
l/h
20000
30000
41000
Max. head height
m
8.00
8.50
10.00
Connection pressure-side
mm
50
Connection pressure-side
2"
Connection suctions-side
mm
50
63
Connection suctions-side
2"
2½"
Connection for hoses
mm
38/50
Connection for hoses
1½", 2"
Filter intake surface
cm²
1320
1620
Coarse debris displacement max.
mm
8
Electronic adjustment
Yes
Setup type
Can be setup underwater & dry
Item no.
56873
56874
56875
81
Side outlet
Side 2″ outlet for easier installation in
large systems.
Ergonomic handle
The ergonomic handle is aligned with
the pump’s centre of gravity facilitates
transport and installation.
Compact base
Integrated fixing holes in the base
facilitate fixed installation on the pond
floor, as needed.
Robust filter basket
Thanks to this robust stainless steel filter
basket, coarse debris particles up to 8 mm
in size are displaced with no problems.
InScenio FM-Profimaster
Wireless remote control garden power
outlet for electronic adjustment.
Item no. 56886 (page 211)
Top 3 product characteristics
•
Powerful pumps for large installations
• Convenient electronic adjustment
• Patented frost protection to –20 °C
Recommendation
The powerful AquaMax Expert is best
suited for supplying filter systems as
well as for watercourses and waterfalls
in larger installations.
OASE-Pump performance curves – comparison see page 246–247
Accessories
Product details
Filter- &Watercourse pumps
AquaMax
