Extras
79
*
P.251
Product details
NEW
NEW
Accessories
AquaMax Eco Control
With the clever DMX-RDM
control device, AquaMax Eco
Control, the capacity of the
connected pumps can be
simultaneously queried
and regulated directly on
the controller! Including
illuminated display, without
separate power supply!
Item no. 40247
InScenio FM-Master WLAN
This innovative garden power outlet
can be controlled via smart phone or
tablet. In addition to 4 power outlets
with an integrated timer, it also
has a DMX-RDM connection for the
AquaMax Eco Expert.
Item no. 40243 (page 208)
Item no. 40244 (page 208)
NEU
Technical data
AquaMax
Eco Expert
21000
AquaMax
Eco Expert
26000
Dimensions (L x W x H)
mm
490 x 215 x 210
Rated voltage
220–240 V/50/60 Hz
Power consumption
W
350
440
Power cable length
m
10.00
Net weight
kg
13.90
Guarantee (+ request guarantee)*
P.251
Years
3 + 2
Max. flow rate
l/min
350
433
Max. flow rate
l/h
21000
26000
Max. head height
m
8.00
8.50
Connection pressure-side
mm
50
Connection pressure-side
2"
Connection suctions-side
mm
50
Connection suctions-side
2"
Connection for hoses
mm
38/50
Connection for hoses
1½", 2"
Connection DMX-RDM
Yes
Electronic adjustment
Yes
Filter intake surface
cm²
1060
Coarse debris displacement max.
mm
11
Setup type
Can be setup underwater & dry
Item no.
39916
39917
Convenient operation
The ergonomic handle, aligned with the
pump’s centre of gravity facilitates trans-
port and installation. The switch for SFC
function is practically positioned directly
on the handle.
Connection for DMX-RDM
control devices
Innovative, convenient and handy, the
AquaMax Eco Expert pumps can be easily
regulated and controlled by devices, such
as the AquaMax Eco Control via a DMX-
RDM connection.
Compact base
Integrated fixing holes in the base
facilitate fixed installation on the pond
floor, as needed.
Robust filter basket
Thanks to this robust stainless steel
filter basket, coarse debris particles
up to 11 mm in size are displaced
with no problems.
Top 3 product characteristics
•
High-performance powerhouse with low
energy consumption offers significant
energy savings
• Patented frost protection to –20 °C
• With switchable SFC function, enabling
an additional 30% savings in energy costs,
depending on the water temperature
Recommendation
The energy-efficient and high-perfor-
mance AquaMax Eco Expert is outstand-
ingly suited for feeding large filter systems,
as well as demanding watercourses and
waterfalls.
Innovative controller and FM-Master
WLAN with DMX-RDM interface for
individual capacity regulation and query,
as accessories.
OASE-Pump performance curves – comparison see page 246–247
AquaMax Eco Expert 21000 - 26000
Q
(l/min)
H
(mWS)
450
6
7
8
9
2
1
200
150
100
3
4
5
26000
21000
250 300
400
350
NEW
NEW
W
NEW
Filter- &Watercourse pumps
AquaMax
