217
Recommendation
Whether on the terrace, in the swim pond
or in the ground - the LunAqua Terra LED
is suitable for various areas of imple-
mentation in the garden or in driveways.
Installation is incredibly easy: Route the
cable, insert the light fixture in the 40
mm bore – a romantic evening atmos-
phere is provided!
*
P.293
Top 3 product characteristics
•
Pleasant warm light out of the ground
for perfect evening atmosphere
• Individual installation possibilities:
In the garden above the water and
underwater
• Easy installation
PRODUCT DETAILS
Extras
TECHNICAL DATA
LunAqua Terra LED
Set 6
LunAqua Terra LED
Set 3
LunAqua Terra LED
Solo
Dimensions (Ø x H)
mm
45 x 15
Rated voltage
–
12 V/AC
Rated voltage (primary, secondary)
230 V/50 Hz , 12 V/AC
Power consumption light fixture
W
0.25
Power consumption set
W
4
3
–
Protection class
IP 68, IP 44 (power unit)
IP 68
Power cable length
m
10
Net weight
kg
2.18
1.3
0.3
Guarantee*
P.293
Years
2
Illuminant type
LED
Light flux
lm
14
Light colour
Warm-white
Colour temperature
K
3000
Half peak angle
Diffuse
Item no. (GB-Version)
Not available in GB!
Item no.
50729
51043
51056
Stainless Steel Watercourses
Can be combined with the OASE stainless
steel watercourse elements. Simply insert
into the illumination element and the
stainless steel watercourse shells become
radiant highlights (fastening accessories
included in the scope of delivery of the
illumination element).
Maximum drive-over weight 3 t
When properly installed, load bearing
capacity for pedestrian and vehicular
traffic up to 3 t Also suitable for yard and
driveway.
Watertight, in accordance with
IP 68 protection rating
Water ingress is not possible! Thanks to
high-quality workmanship and protection
class IP 68 for continuous safe operation
underwater and above the water (IP 44
connection).
Extension cable
10 m extension cable available as an
accessory and suitable for bulb and 6x
connector (max. 2 x per strand)
Accessories
LunAqua Terra LED
Extension cable 10m
Item no. 51057 (page 242)
Stainless steel watercourse
illumination
Item no. 50809 (page 277)
ILLUMINATION & POWER
LED SPOTLIGHTS
