225
LUNAQUA MAXI LED
Stainless steel design and flexible functionality
• Warm white 3 W power LED in 1 unit or 3 unit set
• Suitable for use underwater and above the water, e.g.
for illumination of a bubbling stone
• Suitable for permanent underwater use, thanks to
protection class IP68 (connection IP 44)
• An additional spotlight, LunAqua Maxi LED Solo, can
be retrofitted in each case (delivery without 12 V)
• Incl. interchangeable optics for a half peak angle of 10°
or 30°
• Wall mount and in ground installation possible
• Incl. ground stake and tool for wall mounting
• Star circuit, 12 V safety transformer and rubber hose line
TECHNICAL DATA
Top 3 product characteristics
•
Energy efficient, warm white 3W power LED
• Flexible in ground/on ground installation and
on wall installation
• An additional spotlight, LunAqua Maxi LED
Solo, can be retrofitted in each case
Recommendation
Thanks to the interchangeable optics the
half peak angle can be quickly and easily
changed from 10° to 30°, to illuminate the
garden and pond.
LunAqua Maxi LED
Set 1
LunAqua Maxi LED
Set 3
*
2
Extras
*
P.293
LunAqua
Maxi
Set 1
LunAqua
Maxi
Set 3
LunAqua
Maxi
LED Solo
Dimensions (Ø x H)
mm
52 x 117
Rated voltage
–
0–12V 700 mA/DC
Rated voltage (primary, secondary)
220 – 240V / 50/60 Hz, 0–12V/700mA/DC
Power consumption light fixture
W
3
Energy efficiency category light fixture*
1
A
Power consumption set
W
5
13
–
Protection class
IP 68, IP 44 (power unit)
IP 68
Cable length 12 V device
m
2.00 (power unit) + 5.00
Net weight
kg
1.8
4.2
1.2
Garantie (+ request guarantee)*
P.293
Years
3 + 2
Illuminant type
LED
Number of individual LEDs
EA
1
Light flux
lm
84
Light colour
Warm-white
Colour temperature
K
2800
Half peak angle
30 Degrees
Item no. (GB-Version)
–
Item no.
50507
50508
50509
*
1
Additional instructions concerning the energy efficiency classes are provided on page 285
*
2
Only applies for LunAqua 3 LED Set 3
ILLUMINATION & POWER
LED SPOTLIGHTS
