Dimension drawing:
LunaLed 6 s
Dimension drawing:
LunaLed 9 s
219
Recommendation
Be creative - combine multiple LunaLeds
using the OASE multiple distributor (page
263) and design your custom fountain.
LunaLed 6 s
LunaLed 9 s
Dimensions (Ø x H)
mm
30 x 70
50 x 70
Rated voltage (primary, secondary)
230 V / 50 Hz, 12 V / DC
Power consumption light fixture
W
< 1
Power consumption set
W
2
Protection class
IP 68, IP 44 (power unit)
Power cable length
m
10.00
Net weight
kg
0.60
0.80
Guarantee*
P.293
Years
2
Connections, inlet
mm
19
25
Connections, inlet
¾"
1"
Illuminant type
LED
Number of individual LEDs
EA
6
9
Light flux
lm
8
10
Light colour
Cold-white
Colour temperature
K
6000
Half peak angle
72 Degrees
Item no. (GB-Version)
Not available in GB!
Item no.
50114
50115
TECHNICAL DATA
*
P.293
Top 3 product characteristics
• High quality stainless steel cap
• Easy installation via hose connectors,
ideal for bubbling stones
• Adjustable water feature height
PRODUCT DETAILS
Extras
Hose connectors
The innovative hose connector makes the
installation easy. The power cable can be
routed out through the opening and does
not need to be threaded through the enti-
re length of the hose.
Stainless steel cap
The high quality stainless steel cap enables
fast adjustment of the water flow rate and
protects the LED from damage.
Amount of water required
The right pump is crucial for an appropri-
ate fountain height; it is best to select the
pump based on the water flow rate. Do not
forget that hose length and diameter also
play a role.
LunaLed 6 s LunaLed 9 s
Height l/min Height l/min
2 cm 3
2 cm 7
3.5 cm 5 3.5 cm 9
6 cm 6
6 cm 11
12 cm 8 12 cm 14
Recommended
supplemental products
Water feature pumps
Aquarius Universal page 34–39
Additional pond construction material,
such as
hoses, hose connectors, etc.
from page 252
