101
Top product characteristics
•
Clear water guaranteed*
P.310
through the
ideal combination of filter, pump and
UVC technology
•
Easy cleaning via the cleaning function
integrated in the cover
•
The filter can be buried to the cover for
perfect integration in the environment
Recommendation
The UVC bulbs should be changed at regular
intervals, ideally in spring before the season
starts, to guarantee the full capacity of the
UVC output!
Accessories
Replacement bulb UVC 7 W
Item no. 57111 (page 154)
Replacement bulb UVC 9W
for BioPress Set 6000
Item no. 54984 (page 154)
Replacement bulb UVC 11 W
Item no. 56112 (page 154)
Replacement foam set
BioPress 4000
Item no. 15558 (page 142)
Replacement foam set
BioPress Set 6000/10000
Item no.
15564 (page 142)
FiltoCap sand
Decorative rock cover suitable for
all BioPress and FiltoClear filters.
Item no. 50420 (page 298)
AquaActiv BioKick 200 ml
To achieve the optimal filter
effect »treatment« with OASE
BioKick filter starter is recom-
mended. This should be added
each time the filter is placed
in service (e.g. spring).
Item no. 50295 (page 196)
Cleaning handle
Easy cleaning via the cleaning function
integrated in the cover.
Quick release
For easy opening and closing of the filter
when performing maintenance tasks.
Integrated UVC unit
The UVC unit integrated in the cover en-
sures fast elimination of algae and reduc-
tion in pathogens in the pond water.
P
Extras
*P.310
*P.310
*1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m
3
!
T
BioPress Set
4000
BioPress Set
6000
BioPress Set
10000
Dimensions (Ø x H)
mm 225 x 335
350 x 450
350 x 570
Rated voltage
230 V / 50 Hz
Power consumption UVC
W
11
12
14
Power consumption pump
W
25
40
70
Power cable length UVC
m
3.00
Power cable length pump
m
10.00
Net weight
kg
5.22
7.60
8.60
Guarantee
*P.310
Years
2
UVC power
W
7
9
11
Number of blue filter foams
EA
1
2
Number of black filter foams
EA
2
1
2
Number of bio-surface elements
EA
-
20
30
Pollutant level indicator
Yes
Temperature display
No
Connection inlet
mm
19 / 25 / 32 / 38
Connection inlet
¾”, 1”, 1 ¼”, 1 ½”
Connections, outlet
mm
19 / 25 / 32 / 38
Connections, outlet
¾”, 1”, 1 ¼”, 1 ½”
Max. operating pressure
bar
0.2
Suitable for ponds up to max.
m³
4.0
6.0
10.0
Suitable for ponds with fish stock
m³
2.0
3.0
5.0
Suitable for ponds with koi
*1
m³
1.0
1.5
2.5
Item no. (GB-Version)
50504
50454
50457
Item no.
50499
50453
50455
Filter materials
In addition to the filter sponges, bio-filter
surfaces with the specially developed flow
control offer supplemental settlement
surface for microorganisms. They are able to
move freely in the water flow
(only BioPress
6000 / 10000)
.
