Schematic diagram: BioSmart Set components in function
Topproduct characteristics
•
Clear water guaranteed through the ideal
combination of filter, pump and UVC
technology
• Complete, optimally matched sets
• Easy filter maintenance thanks to
pollutant level indicator, cleaning handles
and sludge drain
Recommendation
The UVC bulbs should be changed at regular
intervals, ideally in spring before the season
starts, to guarantee the full capacity of the
UVC output!
B S S
Solid flow through filter sets with UVC and filter pump
• Suitable for ponds up to 36 m³
• Combination of mechanical biological cleaning and effective UVC
technology
• Incl. OASE Clear Water Guarantee*
P.310
• Oxygen enrichment through special water channelling
• Cleaning handles for convenient maintenance
• Including displays for pollutant level and water temperature
• Sludge drain for easy removal of coarse debris
• Easy to conceal; the filter housing can be recessed into the
ground to
¹
/
³
of its height
• Filters and pumps are optimally matched
• Incl. 100 ml BioKick Filter Starter*
1
BioSmart Set 5000
• Included in the scope of delivery: 3 m ¾“ hose and OASE filter pump
1500: 25 W; 1,500 l/h Qmax; 1.9 m Hmax
BioSmart Set 7000
• Included in the scope of delivery: 3 m ¾“ hose and OASE filter pump
2500: 40 W; 2,500 l/h Qmax; 2.2 m Hmax
• Included in the scope of delivery: 3 m ¾“ hose and OASE filter
BioSmart Set 14000
• Included in the scope of delivery: 3 m ¾“ hose and OASE filter pump
3500: 70 W; 3,400 l/h Qmax; 2.7 m Hmax
BioSmart Set 18000
• Included in the scope of delivery: Vitronic UVC 18 W; 5 m 1½“ hose and
OASE AquaMax Eco Classic 5500: 60 W; 5,300 l/h Qmax; 2.8 m Hmax
BioSmart Set 24000
• Included in the scope of delivery: Vitronic UVC 24 W; 5 m 1½“ hose and
OASE AquaMax Eco Classic 5500: 60 W; 5,300 l/h Qmax; 2.8 m Hmax
BioSmart Set 36000
• Included in the scope of delivery: Vitronic UVC 36 W; 5 m 1½” hose and
OASE AquaMax Eco Classic 11500: 100 W; 11,000 l/h Qmax; 3.3 m Hmax
*
1
Only BioSmart Set 18000–36000
*
P. 310
START
BioSmart Set 5000
BioSmart Set 18000
Extras
