117
Brushes and mat meshwork
For separating the coarse debris.
Filter foams
For settlement of microorganisms for
decomposition of pollutants and nutri-
ents.
Ball valve
Clean water outlet back to the pond
lowers the water level in the filter and
enables water saving filter cleaning.
Discharge chamber
with DIN 110 connection
P
Top product characteristics
•
Large settlement surfaces for filter
bacteria
• Low maintenance multi zone filter
system with long service life
• For large ponds up to 120 m³
Recommendation
The BioTec 30 is an important component
of the BioTec filter systems, see selection
table (page 121).
Matching filter and watercourse pumps:
AquaMax Eco Premium 12000 /
16000 / 20000 (page 66),
AquaMax Eco Twin 20000 / 30000 (page 70)
Matching UVC clarifiers:
Bitron C 72 W– 110W (page 148)
Bitron Eco 120W– 220W (page 150)
AquaActiv BioKick Premium
BioKick Premium, the filter
starter for pros with more than
50 billion microorganisms/
ml. Quickly provides adequate
biology in the filter, whether at
restart or after cleaning.
Item no. 51280
(page 197)
Accessories
Replacement foam
blue BioTec 5 / 10/ 30
10x Item no. 54031 (page 143)
red BioTec 5 / 10/ 30
4x Item no. 54030 (page 143)
Discharge pipe
black DN 75/ 480 mm
Item no. 55043
(page 280)
black DN 110/ 480 mm
Item no. 50427
(page 280)
T-piece
black DN 75
Item no. 55046
(page 280)
Connection elbow
black DN 75 / 45°
Item no. 55044
(page 280)
black DN 75 / 87°
Item no. 55045
(page 280)
black DN 110/ 45°
Item no. 50430
(page 280)
Extras
*P.310
*1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m
3
!
T
BioTec 30
Dimensions (L x W x H)
mm
1200 x 800 x 730
Net weight
kg
81.50
Guarantee
*P.310
Years
3
Number of filter brushes
EA
6
Number of filter mats
EA
5
Number of filter foams, total
EA
14
Number of blue filter foams
EA
10
Number of red filter foams
EA
4
Temperature display
No
Connection inlet
mm
25 / 32 / 38 / 50
Connection inlet
1”, 1 ¼”, 1 ½”, 2”
Connections, outlet
DN 110
Connections, sludge discharge
DN 75
Max. flow rate
l/h
23000
Suitable for ponds up to max.
m³
120.0
Suitable for ponds with fish stock
m³
60.0
Suitable for ponds with koi
*1
m³
30.0
Connection to
Bitron C 72 - 110 W, Bitron Eco 120 - 240 W
Item no. (GB-Version)
−
Item no.
55421
F -
F , UVC & A
