113
*P.310
*P.310
*1
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m
3
!
*2
As compared with devices without an energy saving function in continuous operation.
T
FiltoMatic
CWS 7000
FiltoMatic
CWS 14000
FiltoMatic
CWS 25000
Dimensions (L x W x H)
mm 380 x 380 x 520 380 x 380 x 720 380 x 580 x 720
Rated voltage
230 V / 50 Hz
Power consumption
W
17
27
Power consumption cleaning
W
41
54
Power cable length
m
10.00
Net weight
kg
9.64
10.70
13.92
Guarantee (+ request guarantee)
*P.310
Years
2 + 1
UVC power
W
11
24
Number of purple filter foams
EA
2
4
Number of red filter foams
EA
1
2
Temperature display
Digital
UVC operating hours meter
8000 h
Connection inlet
mm
38
Connection inlet
1 ½”
Connections, outlet
DN 75
Connections, sludge discharge
DN 40
Min. flow rate
l/h
2500
3500
Max. flow rate
l/h
4000
5000
6000
Suitable for ponds up to max.
m³
7.0
14.0
25.0
Suitable for ponds with fish stock
m³
3.5
7.0
12.5
Suitable for ponds with koi
*1
m³
2.0
3.5
6.5
Item no. (GB-Version)
-
-
-
Item no.
50906
50910
50925
Top product characteristics
•
Up to 40% power savings*
2
thanks to
UVC unit that is activated as needed
•
Virtually invisible, the filter device can be
buried to 70% of the device height
•
Low maintenance and user friendly
Accessories
Replacement bulb UVC
UVC 11 W
Item no. 56112
(page 154)
UVC 24W
Item no. 56237
(page 154)
Filtercartridge set
FiltoMatic CWS 7000
Item no. 50901
(page 142)
FiltoMatic CWS 14000
Item no. 50904
(page 142)
FiltoMatic CWS 25000
Item no. 50904
(page 142)
Discharge pipe
black DN 75/480 mm
Item no. 55043
(page 280)
black DN 40/480 mm
Item no. 50307
(page 280)
T-piece
black DN 75
Item no. 55046
(page 280)
Connection elbow
black DN 40/ 45°
Item no. 50308
(page 280)
black DN 75 / 45°
Item no. 55044
(page 280)
black DN 75 / 87°
Item no. 55045
(page 280)
Decorative rock cover
suitable for all
FiltoMatic CWS filters
FiltoMatic Cap
CWS L
Item no. 50268
(page 298)
CWS XL
Item no. 50269
(page 298)
Recommendation
Discover the other components of the
Clear Water System: The filter pump
AquaMax Eco Premium, the surface skim-
mer SwimSkim 50, and the Aerator OxyTex.
AquaActiv BioKick 200 ml
To achieve the optimal filter
effect »treatment« with OASE
BioKick filter starter is recom-
mended. This should be added
each time the filter is placed
in service (e.g. spring).
Item no. 50295 (page 196)
Automatic control unit
The innovative control system ensures
energy savings through a temperature
controlled UVC unit and automatic clea-
ning intervals.
Filter cover
Easy to open and close with one hand. Un-
intentional opening is prevented through
integrated lock element.
Compact design
Strong filter effect in the smallest space.
With the FiltoCap the device can be buried
so that it is virtually invisible.
Cleaning
In addition to the automatic sludge
discharge, the sponge elements are clea-
ned conveniently, your hands stay clean.
P
Matching filters and filter systems on page 66
Extras
F -
F
, UVC & A
