Temperature display
The thermometer indicates the current
water temperature at all times.
P
*P.310
*1
*2 *P.310
*1
*1
BioSmart UVC 16000
*2
BioSmart 18000/36000
*3
Note: When planning a new pond with koi stock, please ensure a minimum pond size of 5 m
3
!
T
BioSmart
UVC 16000
BioSmart
18000
BioSmart
36000
Dimensions (L x W x H)
mm 380 x 560 x 410 382 x 555 x 408 767 x 555 x 408
Rated voltage
230 V / 50 Hz
-
Power consumption
W
14
-
Power cable length
m
3.00
-
Net weight
kg
5.40
5.50
10.70
Guarantee
*P.310
Years
2
3
UVC power
W
11
-
Number of filter foams, total
EA
6
4
9
Number of blue filter foams
EA
3
2
4
Number of red filter foams
EA
3
1
4
Number of green filter foams
EA
-
1
Temperature display
Yes
Connection inlet
mm 19 / 25 / 32 / 38
25 / 32 / 38
Connection inlet
¾”, 1”, 1 ¼”, 1 ½”
1”, 1 ¼”, 1 ½”
Connections, outlet
DN 75
Connections, sludge discharge
mm
38
-
Connections, sludge discharge
1 ½”
DN 50
Max. flow rate
l/h
5500
8000
Suitable for ponds up to max.
m³
16.0
18.0
36.0
Suitable for ponds with fish stock
m³
8.0
9.0
18.0
Suitable for ponds with koi
*1
m³
4.0
4.5
9.0
Item no. (GB-Version)
Not²available²in GB
−
Item no.
57377
56776
56641
Nitrification and de-nitrifica-
tion zone
Toxic ammonia, nitrite and nitrate are
effectively transformed into harmless end
products in the different foams.
UVC unit
TheintegratedUVCunitensuresfastelim-
inationofsuspendedalgaeandreduc-
tionofpathogens. (only BioSmart UVC
16000)
Particularly easy maintenance
After activating the cleaning lever, the
floor discharge can be opened and coarse
debris can be disposed of (only BioSmart
18000/36000).
Recommendation
The perfect supplement for the Flow
through filter: Thanks to the clever design
the UVC clarifiers, Vitronic 18W - 36W can
easily be connected to the BioSmart 18000
and 36000.
Top product characteristics
• Reliable and flexible implementation –
entry-level flow-through filter
• Easy maintenance thanks to cleaning
handles and bottom drain
• Pollutant level indicator and temperature
indicator for convenient filter monitoring
Accessories
Replacement bulb UVC 11 W
Item no.
56112 (page 154)
Replacement foam BioSmart UVC
16000
Red
Item no.
35791 (page 142)
Blue
Item no.
35792 (page 142)
Replacement foam BioSmart
18000 / 24000 / 36000
Red
Item no.
56677 (page 142)
Blue
Item no.
56678 (page 142)
Green
Item no.
56679 (page 142)
Discharge pipe
Black DN 75 / 480 mm
Item no.
55043 (page 280)
t-piece
Black DN 75
Item no.
55046 (page 280)
Connection elbow
Black DN 75 / 45°
Item no.
55044 (page 280)
Black DN 75 / 87°
Item no.
55045 (page 280)
AquaActiv BioKick 200 ml
To achieve the optimal filter
effect »treatment« with OASE
BioKick filter starter is recom-
mended. This should be added
each time the filter is placed in
service (e.g. spring).
Item no.
50295 (page 196)
