129
*P.310
*P.310
T
ProfiClear Classic
pump chamber
ProfiClear pump
chamber
Compact/Classic
ProfiClear Classic
coarse debris
extrac.
ProfiClear Classic
filter foam
module
ProfiClear Classic
phosphate binder
mod.
Dimensions (L x W x H)
mm 830 x 600 x 820
830 x 665 x 820
830 x 600 x 820
Net weight
kg
34.40
35.00
38.50
43.00
46.00
Guarantee (+ request guarantee)
*P.310
Years
2 + 1
Coarse debris extraction
µm
-
800
-
Biological filter surface
m²
-
90.0
148.0
Special filter granulate
kg
-
4.00
Number of blue filter foams
EA
-
3
-
Number of red filter foams
EA
-
3
-
Number of black filter foams
EA
-
6
Temperature display
-
No
Inlets ProfiClear Classic
2 x DN 110 / 1 x DN 150
1 x DN 110 / DN 150 + 2 x DN 50
Outlets ProfiClear Classic
25 - 50 mm (1” - 2”) + 1 x DN 50
1 x 2” / 2 x DN 110
1 x DN 110 / DN 150
Connections, sludge discharge
DN 75
Max. flow rate
l/h
25000
12500
Rec. flow rate (pump-fed)
l/h
-
8000
Rec. flow rate (gravity-fed)
l/h
-
6000
Other
• Pollutant discharge incl. slide valve
Product characteristics
Whether the OASE
modular filtration
system is operated
as a gravity-fed filter
in the ground or as a
pump-fed version. The
ProfiClear Classic pump
chamber ensures the
correct positioning of
the filtration pump:
• Safe and standard
conformant set-up
at swim ponds
• Easy maintenance
and winter care
• Protection against
excessive silt
• Debris that accumu-
lates in the sediment
tank is flushed out
via the bottom
drain
1
Note: A suitable DN110
slide valve can be
ordered separately
as an accessory item:
27171 (see ProfiClear
accessories)
Enables space-saving
and energy-efficient
integration of up to
two Aqua-Max Eco
Gravity and Bitron
Gravity units.
• Maximum flexibility
in the connection
through 2 x DN110
and 2” transitions
• For integration in
the ProfiClear Pre-
mium Compact and
ProfiClear Classic
gravity-fed systems
• Reduction of pres-
sure losses
• Safe and standard
conformant set-up
at swim ponds
• Easy maintenance
and winter care
• Protection against
excessive silt
• Debris that
accumulates in the
sediment tank is
flushed out via the
bottom drain
• Enables space-sav-
ing and energy-effi-
cient integration of
up to two AquaMax
Eco Gravity and
Bitron Gravity units
• Maximum flexibility
in the connection
through DN 110 and
2” container outlets
• For integration in
the ProfiClear Pre-
mium Compact and
ProfiClear Classic
gravity-fed systems
Enables easy mechani-
cal extraction of solids
up to 800µm in size.
• Incoming water
is fed through
two large-surface
extraction sieves
1
into the next filter
chamber
• Pulling the slide
valve
2
flushes the
debris out via a DN
75 discharge
• Incl. garden hose
coupling for fresh
water rinsing
• The extraction sieves
are quickly cleaned
with interior and
exterior brushes by
operating the clean-
ing handle.
3
• A pollutant level
indicator
4
signals
when maintenance
is required
• Automatic and regu-
lar cleaning is possi-
ble via the ProfiClear
Screendrive (optional
accessory)
The ProfiClear Classic
filter foammodule en-
sures safe removal of
toxic substances like
ammonium/ammonia
or nitrite.
• The water that is
to be filtered is
channelled through
the coarse and fine
foams
1
that con-
tain the vital filter
biology
• The oxygen
necessary for the
nitrification pro-
cesses is supplied
via connections on
the housing
• The foams are
cleaned by com-
pressing against the
intermediate floor
via the cleaning
levers
2
.
• Pulling the slide
valve
3
flushes the
debris out via a DN
75 discharge, which
can be supported by
rinsing via a garden
hose adapter
The ProfiClear Classic
phosphate binder
module converts
nitrate into gaseous
nitrogen (denitrifica-
tion) and eliminates
phosphates.
• A majority of the
water is channelled
past the
1
filter
foam. This establish-
es the low oxygen
milieu that is so
important for the
denitrifying bacteria
• The lesser portion of
the flow volume is
channelled through
the PhosLess inserts
2
(4 units)
• Binders ensure quick
and safe phosphate
removal
• Elimination of these
nutrients signifi-
cantly restricts string
algae growth
• Virtually mainte-
nance-free because
bypass regulation in
the foam prevents
clogging
• A pollutant level
indicator
3
signals
when maintenance
is required
• Pollutant discharge
4
incl. slide valve
Item no. (GB-Version)
−
−
−
−
−
Item no.
51061
42913
51064
51065
51066
A
A
B
C
D
1
2
3
4
1
2
3
1
2
3 4
1
1
NEW
M -
F , UVC & A
