ProfiClear Premium
Drum filter pump-fed EGC
ProfiClear Premium
Drum filter gravity-fed EGC
Dimensions (L x W x H)
mm
830 x 600 x 820
Rated voltage
230 V / 50 Hz
Power consumption
W
5
Power consumption cleaning
W
1050
Cable length
m
5.00 + 1.00
5.00 + 5.00
Net weight
kg
74.00
74.50
Guarantee (+ request guarantee)
*P.310
Years
2 + 1
Control unit
Microcontroller
Temperature display
Digital
Coarse debris extraction
µm
60
Number of nozzles / cleaning flow rate
4 x 2.5 l/min
Scavenging pump
6 bar
Automatic self cleaning
manually, Sensor, Time interval
Number of sieve elements
EA
8
Filter intake surface
cm²
3454
4200
Material
GRP Duroplast/stainless steel
Number of inlets
EA
2
4
Connection inlet
mm
50
-
Connection inlet
2 x 2” + Bitron
DN 110
Number of outlets
EA
2
Connections, outlet
DN 150
Connections, sludge discharge
DN 75, DN 110
Connection mud drain
DN 110
Connection to
Bitron C 72 - 110 W, Bitron Eco 120 - 240 W
Bitron Gravity
Min. flow rate
l/h
10000
Max. flow rate
l/h
25000
33000
Installation height above water level
cm
40.0
11.5
Pos. water level difference
5 cm
-20 mm
Type of use
Pump fed system
Gravity fed system
Other
• Pollutant discharge incl. slide valve
Product characteristics
• Deep-bed filtration with a filter capacity to 60 µm
• Automatic self-cleaning
• A microcontroller system, suitable for outdoor use,
monitors and controls the functions
• Individually removable sieve elements (no tools
required) and free-wheeling functions for easy
access to the drum
• Particularly quiet in operation
• Quality high-pressure pump for flushing the drum
in the scope of delivery
• Possibilities for connection to the Easy Garden
Control System (EGC)
• Safety level switch prevents jamming due to debris
particles
• Additional 2” inputs with non-return valve for
integration of additional pumps
• Flow capacity up to 25 m³/h
• Deep-bed filtration with a filter capacity to 60 µm
• Automatic self-cleaning
• A microcontroller system, suitable for outdoor use,
monitors and controls the functions
• Individually removable sieve elements (no tools
required) and free-wheeling functions for easy
access to the drum
• Particularly quiet in operation
• Quality high-pressure pump for flushing the drum
in the scope of delivery
• Possibilities for connection to the Easy Garden
Control System (EGC)
• Full flexibility for the connection with up to 4x DN
110 inlets
• Full design freedom with just 11 cm installation
height above the water level
• Supplemental sensor detects failure of the feed
pump and reports this via display or EGC
• Flow capacity up to 33 m³/h
Item no. (GB-Version)
47004
47006
Item no.
47003
47005
