Flexible with maximum effectiveness.
The filter system is flexibly aligned to the
individual conditions of the body of water.
• Space-saving pump and UVC chamber
for easy integration of:
AquaMax Eco gravity filter pumps and
Bitron Gravity UVC clarifiers
• Maximum flexibility in the connection
through DN 110 and 2" ducts
• To increase the filter capacity, it’s possible
to fill the 2 individual baskets in the flow
area with additional filter medium up to
8 litres fill volume
• Integrated bottom drain with high quality,
finely engineered slide valve
Intelligence sets the pace. The intelligent
switch centre removes coarse debris to
60 µm – i.e. finer than a strand of hair.
• Maximum particle removal to 60 µm and
flow-through rates to 33 m³/h for a crystal
clear view
• Flexible implementation possibilities;
can be used in the gravity-fed system,
as well as in the pump-fed system
• Automatic self-cleaning offers maximum
convenience
• Rinsing is executed with cleaned pond
water, a water connection is not required
• A watertight microcontroller system
monitors and controls the main functions,
operation is as easy as child’s play
(plug & play)
• Control system with retrospective display
of errors in running operation as well as
adjustment possibilities for forced cleaning,
duration of cleaning and supplemental
cleaning
• Pollutant rakes on the sieves reliably re-
move string algae and other larger particles
from the drum
• Pollutant trough made of ductile EPDMma-
terial prevents jamming of larger particles
• VDE testing certifies reliable and safe
functions
• Safety level switch in the pump-fed system
prevents jamming due to debris particles
• Stable housing thanks to solid stainless
steel elements and dimensionally stable
Duroplast
• Individually removable sieve elements
(no tools required) and free-wheeling func-
tions for easy access to the drum interior
• Incomparably quiet through extensive
noise damping
• Powerful, high-quality pressure pump is
integrated for flushing the drum
• Full flexibility for the connection with
up to 4x DN 110 inlets
• Screen elements in 150 µmmesh width
optionally available as accessories
Hel-X ensures optimummedia circulation
Original Hel-X biomedia are highly effective
at degrading pollutants in the moving
bed process.
• Extremely large, protected settlement
surface for microorganisms (806 m²/m³)
• Innovative bypass technology for optimal
movement of the Hel-X bio-elements even
with high flow rates
• Removal of toxins, such as ammonium/
ammonia, nitrite and nitrate
• Hel-X Biomedium 50 l decompose
approx 340 g of fish food per day. Its per-
formance depends on temperature, feed
quality and the degree of settlement
of microorganisms
• Aerator bar for oxygen enrichment and
turbulence already installed
• Advantages of the moving bed process:
Permanent, optimal oxygen supply;
self-cleaning effect from dead biomass,
know-how from industrial water treat-
ment
• Integrated bottom drain with high quality,
finely engineered slide valve
D
M B M
I
M
Integrated aerator can be connected to
AquaOxy aerator pumps.
It was possible to significantly extend the
surface that can be settled (surface protected:
+ 14.5% relative to the predecessor product).
Convenient filling of the 2 individual baskets
with up to 8 litres fill volume.
NEW
Now with
