Top product characteristics
•
Remote controlled water feature with
varying fountains and white LED
illumination
• Easy installation thanks to »Plug’n Spray«
• Can be used in swim ponds thanks to 12 V
technology
Recommendation
Splash water can be minimised by selecting a
pool with at least a 3 m diameter. The OASE
water reservoir WR 100 can be extended with
pond liner, for example.
Luminous fountains for modern garden design
21
3 product ch racteristics
Schematic diagram: Water Trio in a reservoir
W T
*page310
T
Water Trio
Dimensions (L x W x H)
mm
430 x 300 x 240
Net weight
kg
8.84
Guarantee (+ request guarantee)
*P.310
Years
2 + 1
Light colour
neutral white
Cable length 12 V device
m
2.50 (Power unit) + 8.00
Fountain height, max.
m
1.40
Jet diameter
mm
5
12 V control box
Dimensions control unit: (L x W x H)
mm
215 x 180 x 305
Power consumption
W
40
Rated voltage, prim. (control system)
V
12
Hand-held transmitter / range max.
m
80.00
Power unit
Dimensions transformer: (L x W x H)
mm
160 x 100 x 100
Rated voltage (primary, secondary)
230 V / 50 Hz, 12 V / DC
Item no. (GB-Version)
−
Item no.
50240
• High quality water feature with three varying fountains, including
LED lighting
• »Plug'n Spray« principle: Immediately
ready for use and easy connection
• Variations in fountain height (30 - 140 cm)
and light intensity can be played back in
permanently set programs
• The programs can be conveniently selected
via remote control from a distance of up to
80 m
• Can be connected to a timer
• Flexible setup on a wide variety of substrates
• Robust floor plate protects against damage
• Easy maintenance
• Low energy consumption
• Safe, energy-efficient 12 V technology
• Can even be used in swim ponds
• Included in the scope of delivery: 3 pumps /
nozzles, external control unit, transformer
and cables
