External control system
Compact and easy to conceal: The control
unit can be easily connected and includes
a transformer as well as a ground stake.
P
Recommendation
Enjoy the different colours of the luminous
water jets at twilight. This is when they
are most effective. The fountain should be
installed where it is protected from wind, so
that the water arches maintain their perfect
form. For maximum enjoyment, ensure
good water quality.
Top product characteristics
• The special feature in the garden: Colour-
ed arching water jets
• »Plug'n Spray« principle: Complete set for
easy connection
• Can be used in swim ponds thanks to 12 V
technology
*page310
T
Water Jet Lightning
Dimensions (L x W x H)
mm
150 x 115 x 200
Net weight
kg
12.10
Guarantee (+ request guarantee)
*P.310
Years
2 + 1
Light colour
RGB
Cable length 12 V device
m
2.50 (Power unit) + 8.00
Parabolic height, max.
m
0.90
Parabolic width, max.
m
1.80
Jet diameter
mm
8
12 V control box
Dimensions control unit: (L x W x H)
mm
215 x 180 x 305
Power consumption
W
41
Rated voltage, prim. (control system)
V
12
Hand-held transmitter / range max.
m
80.00
Power unit
Dimensions transformer: (L x W x H)
mm
160 x 100 x 100
Rated voltage (primary, secondary)
230 V / 50 Hz, 12 V / DC
Item no. (GB-Version)
−
Item no.
50191
Accessories
InScenio FM-Master WLAN
This innovative garden power
outlet can be controlled via smart
phone or tablet. In addition to 4
power outlets with an integrated
timer, it also has an EGC connec-
tion.
Item no. 40243 page 242
InScenio FM-Master WLAN EGC
Item no. 47035 page 242
Remote control
The remote control unit (433 MHz) includ-
ed in the scope of delivery has a range of
up to 80 m without obstruction.
High-quality materials
In addition an appealing design – total
Water Entertainment from OASE.
Adjustable jet angle
Because the angle of the Water Jet
Lightning units can be adjusted there are
many variation possibilities.
Throw length can be adjusted individually (2 x distributor)
