External control system
Compact and easy to conceal: The control
unit can be easily connected and includes
a transformer as well as a ground stake.
Illuminated nozzles
The individually controllable nozzles, each
with 6 LEDs, are easy to align.
Height adjustable
The nozzles of the fountain are height
adjustable, so that the water level can
vary by 20 cm.
P
Top product characteristics
• Remote controlled water feature with
varying fountains and white LED illumi-
nation
• Water patterns can be selected from the
set programs
• Can be used in swim ponds thanks to 12 V
technology
*page310
T
Water Quintet
Water Quintet
Creative
Dimensions (L x W x H)
mm
430 x 300 x 240
110 x 80 x 125
Net weight
kg
11.30
10.80
Guarantee (+ request guarantee)
*P.310
Years
2 + 1
Light colour
neutral white
Cable length 12 V device
m
2.50 (Power unit) + 8.00
Fountain height, max.
m
1.40
Jet diameter
mm
5
12 V control box
Dimensions control unit: (L x W x H)
mm
215 x 180 x 305
Power consumption
W
50
Rated voltage, prim. (control system)
V
12
Hand-held transmitter / range max.
m
80.00
Power unit
Dimensions transformer: (L x W x H)
mm
160 x 100 x 100
Rated voltage (primary, secondary)
230 V / 50 Hz, 12 V / DC
Item no. (GB-Version)
−
Not©available©in GB
Item no.
50187
50394
Accessories
InScenio FM-Master WLAN
This innovative garden power
outlet can be controlled via smart
phone or tablet. In addition to 4
power outlets with an integrated
timer, it also has an EGC connec-
tion.
Item no. 40243 page 242
InScenio FM-Master WLAN EGC
Item no. 47035 page 242
Water reservoir cover Trio/Quintet
Tailored opening for the »Water
Trio« and »Water Quintet« foun-
tains. Additional service opening
with cover.
Item no. 50327 page 299
Water reservoir WR 100
The weather-resistant solution for
flexible installation.
Item no. 37112 page 299
Pond foils
Almost any idea can be realised
with OASE pond liner. Additional
information
page 262
Remote control
The remote control unit (433 MHz) includ-
ed in the scope of delivery has a range of
up to 80 m without obstruction.
Recommendation
Splash water can be minimised by selecting a
pool with at least a 3 m diameter. The OASE
water reservoir 100 can be extended with
pond liner, for example. Extend the service
life of your fountains and ensure lasting high
performance with the special PumpClean
cleaner.
